Features
● 86mm frame depth
● 22mm insulated glass
● 1.5mm extruded aluminum thickness
● 100μ Powder coating thickness
● German hardware for 10 years warranty.
● Opens to 90° for maximum ventilation
● EPDM full sealing ensures complete weather proofing
Window Options
● A range of glazing options to achieve higher thermal performance
● Can fit with retractable fly screen for preventing insects
● Build in blinds for sun shading function
● Can be in anodized coating for corrosion environment
● Federation or Colonial glazing bars
● A variety of window style configurations
Window Performance
Test Description | Test Result | Rating |
Ultimate Strength | 2700 Pa | C2 |
Water Penetation | 300 Pa | C3 |
Wind Load Capacity | 1600 Pa | C4 |
Air Infiltration | 1.51 L/S Square meter | High |
Window Colors
Laimeng chooses thicker anodized or powder coated aluminum for its strong and durable finish, to provide 10-20 years of quality satisfaction. We offer a standard range of colors to choose from, or can create a custom color to suit your individual design needs.
